Associated Spring Raymond - 16mm Hole Diam, 8mm Rod Diam, 1-3/4" Free Length, Green Die Spring - 307.8 N Max Deflection, 18mm Max Deflection, Light Duty, Chromium Alloy Steel
Item #: 67898494
Brand: Associated Spring Raymond
Model #: 203-307
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Hole Diameter (mm) | 16.00 |
| Rod Diameter (mm) | 8.00 |
| Free Length (mm) | 44.00 |
| Free Length (Inch) | 1-3/4 |
| Load Type | Light-Duty |
| Color | Green |
| Maximum Deflection Load (N) | 307.80 |
| Maximum Deflection (mm) | 18.00 |
| Travel To Solid Load (mm) | 18.00 |
| Wire Shape | Trapezoidal |
| Material | Chromium Alloy Steel |
| ISO Number | 10243 |
