Associated Spring Raymond - 1/2" Bolt, Grade 1075 High Carbon Steel, Uncoated Curved Disc Spring - 0.151" High, 0.021" Thick
Item #: 69130276
Brand: Associated Spring Raymond
Model #: U5000211
Exact Tooling IR#: 04
Features and Benefits
Curved disc springs create a spring-like action and can support heavy loads. They are slightly bent along the outside diameter.
| Product Specifications | |
|---|---|
| Type | Curved Disc Spring |
| Bolt Size (Inch) | 1/2 |
| Bolt Size (mm) | 12.70 |
| System of Measurement | Inch |
| Material | High Carbon Steel |
| Material Grade | 1075 |
| Thickness (mm) | 0.53 |
| Thickness (Decimal Inch) | 0.0210 |
| Overall Height (mm) | 3.84 |
| Overall Height (Decimal Inch) | 0.1510 |
| Deflection (Decimal Inch) | 0.0660 |
| Deflection (mm) | 1.68 |
| Minimum Inside Diameter (Decimal Inch) | 0.5250 |
| Minimum Inside Diameter (mm) | 13.34 |
| Maximum Outside Diameter (Decimal Inch) | 1.2250 |
| Maximum Outside Diameter (mm) | 31.12 |
| Load at Deflection (Lb.) | 25.00 |
| Load at Deflection (N) | 111.21 |
| Finish/Coating | Uncoated |
| Bolt Size (Decimal Inch) | 1/2 |
