Square D - SPDT, NC/NO, 600 VAC, Screw Terminal, Roller Lever Actuator, General Purpose Limit Switch - 1, 2, 4, 6, 12, 13, 6P NEMA Rating, Surface Mount
Item #: 69682656
Brand: Square D
Model #: 9007AEQ2724
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Actuator Type | Roller Lever |
| Voltage | 600 VAC |
| Contact Form | SPDT |
| Contact Configuration | NC/NO |
| Terminal Type | Screw Terminal |
| Mounting Type | Surface Mount |
| Connection Type | 1/2 NPT |
| Material | Silver (Contact); Zinc Alloy (Body) |
| Amperage | 10 |
| Actuator Length (Decimal Inch) | 2 |
| NEMA Rating | 1; 2; 4; 6; 12; 13; 6P |
| Travel (Degrees) | 4 |
| Maximum Operating Temperature (F) | 185 |
| Minimum Operating Temperature (F) | -20 |
| Standards Met | UL Listed File Number E42259 CCN NKCR - CSA Certified File Number LR25490 Class 3211-03 - CE Marked |
