Guardian Electric - 392 Milliamp, 0.05 to 1 Inch Stroke, Pull Force, C Frame Electrical Solenoid - 24 VDC Volt, Quick Connect, 1.98 Inch Long
Item #: 74097643
Brand: Guardian Electric
Model #: 4-C-24D
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Solenoid Type | C-Frame |
| Action | Pull |
| Maximum Stroke (Decimal Inch) | 1 |
| Minimum Stroke (Decimal Inch) | 0.0500 |
| Maximum Pull Force (oz.) | 100 |
| Minimum Pull Force (oz.) | 1 |
| Amperage (mA) | 392 |
| Voltage | 24 VDC |
| Terminal Type | Quick Connect |
| Overall Length (Decimal Inch) | 1.9800 |
| Overall Width (Decimal Inch) | 1.6200 |
| Overall Height (Decimal Inch) | 1.5700 |
| Coil Resistance (Ohms) | 61.30 |
| Duty Cycle | Continuous |
| Standards Met | RoHS Compliant 2002/95/EC; UL Recognized |
