Guardian Electric - 0.83 Amp, 0.05 to 1 Inch Stroke, Pull Force, Box Frame Electrical Solenoid - 24 VDC Volt, Quick Connect, 1.84 Inch Long
Item #: 74098013
Brand: Guardian Electric
Model #: 11-I-24D
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Solenoid Type | Box Frame |
| Action | Pull |
| Maximum Stroke (Decimal Inch) | 1 |
| Minimum Stroke (Decimal Inch) | 0.0500 |
| Maximum Pull Force (oz.) | 62 |
| Minimum Pull Force (oz.) | 5 |
| Amperage | 0.83 |
| Voltage | 24 VDC |
| Terminal Type | Quick Connect |
| Overall Length (Decimal Inch) | 1.8400 |
| Overall Width (Decimal Inch) | 0.9400 |
| Overall Height (Decimal Inch) | 1.1900 |
| Coil Resistance (Ohms) | 29.10 |
| Duty Cycle | Intermittent |
| Standards Met | RoHS Compliant 2002/95/EC; UL Recognized |
