Dayton Lamina - 3/8" Hole Diam, 3/16" Rod Diam, 1-1/4" Free Length, Yellow Die Spring - 14.6 Lb Max Deflection, 0.31" Max Deflection, Extra Heavy Duty, Chromium Vanadium Steel
Item #: 76016021
Brand: Dayton Lamina
Model #: 9-0605-36
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Hole Diameter (Inch) | 3/8 |
| Rod Diameter (Inch) | 3/16 |
| Free Length (Inch) | 1-1/4 |
| Load Type | Extra Heavy-Duty |
| Color | Yellow |
| Maximum Deflection Load (Lb.) | 14.60 |
| Maximum Deflection (Decimal Inch) | 0.3100 |
| Travel To Solid Load (Decimal Inch) | 0.3700 |
| Wire Shape | D-Shaped |
| Material | Chromium Vanadium Steel |
