Dayton Lamina - 1/2" Hole Diam, 9/32" Rod Diam, 1-3/4" Free Length, Yellow Die Spring - 17.5 Lb Max Deflection, 0.43" Max Deflection, Extra Heavy Duty, Chromium Vanadium Steel
Item #: 76016245
Brand: Dayton Lamina
Model #: 9-0807-36
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Hole Diameter (Inch) | 1/2 |
| Rod Diameter (Inch) | 9/32 |
| Free Length (Inch) | 1-3/4 |
| Load Type | Extra Heavy-Duty |
| Color | Yellow |
| Maximum Deflection Load (Lb.) | 17.50 |
| Maximum Deflection (Decimal Inch) | 0.4300 |
| Travel To Solid Load (Decimal Inch) | 0.5600 |
| Wire Shape | D-Shaped |
| Material | Chromium Vanadium Steel |
