Climax Metal Products - 5/8" Bore Diam, 1-1/2" OD, Shaft Locking Device - 4 Screws, 3/4" OAW, 1,708 Ft/Lb Max Torque
Item #: 77957645
Brand: Climax Metal Products
Model #: C192E-062
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Bore Diameter (Inch) | 5/8 |
| Bore Diameter (Decimal Inch) | 0.6250 |
| Outside Diameter (Decimal Inch) | 1.5000 |
| Overall Width (Decimal Inch) | 0.7500 |
| Maximum Torque (Ft/Lb) | 1708 |
| Number of Screws | 4.000 |
| Contact Pressure on Hub (psi) | 10348.000 |
| Contact Pressure on Shaft (psi) | 24827.000 |
