Electro Hardware - 0.089" ID x 3/16" OD, #2 Screw, Grade T-3 Aluminum Female Unthreaded Circuit Board Spacer - Round Body, Uncoated, 1/2" OAL
Item #: 82427188
Brand: Electro Hardware
Model #: S309M04F16C
Exact Tooling IR#: 04
Features and Benefits
Female unthreaded circuit board spacers do not have threads and resemble a plain, cylindrical tube. They are the most common type of spacer.
Aluminum has a high strength-to-weight ratio and is wear resistant, nonmagnetic and conductive. It is easier to form and machine than steel and is naturally noncorrosive.
| Product Specifications | |
|---|---|
| Type | Female Unthreaded |
| Material | Aluminum |
| System of Measurement | Inch |
| Body Shape | Round |
| Screw Size | #2 |
| Outside Diameter (Decimal Inch) | 0.1875 |
| Outside Diameter (Inch) | 3/16 |
| Overall Length (Decimal Inch) | 0.5000 |
| Overall Length (Inch) | 1/2 |
| Inside Diameter (Decimal Inch) | 0.089 |
| Finish/Coating | Uncoated |
| Material Grade | T-3 |
| Inside Diameter Tolerance (Decimal Inch) | 0.000 to 0.010 |
| Length Tolerance (Decimal Inch) | -0.005 to 0.005 |
| Fastener Standard | QQ-A-225A Comp 2 |
