Climax Metal Products - M6 Thread, 1-1/4" Bore Diam, 2.362" OD, Shaft Locking Device - 8 Screws, 10,024 Lb Axial Load, 2.618" OAW, 0.669" Thrust Ring Width, 522 Ft/Lb Max Torque
Item #: 87793386
Brand: Climax Metal Products
Model #: C133E-125
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Thread Size | M6 |
| Bore Diameter (Decimal Inch) | 1.2500 |
| Outside Diameter (Decimal Inch) | 2.3620 |
| Thrust Ring Width (Decimal Inch) | 0.669 |
| Overall Width (Decimal Inch) | 2.6180 |
| Axial Load Lbs (Pounds) | 10024 |
| Maximum Torque (Ft/Lb) | 522 |
| Number of Screws | 8.000 |
| Contact Pressure on Hub (psi) | 16818.000 |
| Contact Pressure on Shaft (psi) | 31781.000 |
| Screw Seating Torque (In/Lb) | 156.000 |
