Seco - SCRC, Right Hand Cut, 75° Lead Angle, 1/2" Shank Height x 1/2" Shank Width, Neutral Rake Indexable Turning Toolholder - 3-1/2" OAL, CCMT 32.52 Insert Compatibility, Series Multi-Directional Turning (MDT)
Item #: 90897687
Brand: Seco
Model #: 13316
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Hand of Holder | Right Hand |
| Toolholder Style | SCRC |
| Rake | Neutral |
| Rake Angle | 0 |
| Series | Multi-Directional Turning (MDT) |
| Lead Angle | 75 |
| Shank Width (Decimal Inch) | 0.5000 |
| Shank Height (Decimal Inch) | 0.5000 |
| Overall Length (Decimal Inch) | 3.5000 |
| Insert Compatibility | CCMT 32.52 |
| Multi-Use Tool | No |
| Insert Holding Method | Screw |
| Back of Bar to Cutting Edge (Decimal Inch) | 0.5480 |
| Head Length (Decimal Inch) | 0.6800 |
| Insert Inscribed Circle (Inch) | 3/8 |
| Insert Inscribed Circle (Decimal Inch) | 0.3750 |
