Iscar - Shank Connection, 1.268" Cutter Diam, 3 Tooth Indexable Slotting Cutter - 1" Shank Diam, TRIB Toolholder, TRI Insert, Right Hand Cutting Direction
Item #: 91150870
Brand: Iscar
Model #: 2302259
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Connection Type | Shank |
| Maximum Depth of Cut (mm) | 0.00 |
| Maximum Depth of Cut (Decimal Inch) | 0.0000 |
| Cutter Diameter (Decimal Inch) | 1.2680 |
| Shank Diameter (Decimal Inch) | 1.0000 |
| Number of Teeth | 3 |
| Toolholder Style | TRIB |
| Series | ChamSlit(TRIB) |
| Insert Style | TRI |
| Number of Cutter Inserts | 3 |
| Cutting Direction | Right Hand |
| Insert Holding Method | Screw |
| Minimum Cutting Width (Decimal Inch) | 0.1580 |
| Maximum Cutting Width (Decimal Inch) | 0.2560 |
| Shank Length (Decimal Inch) | 2.3500 |
| Weldon Flat | Yes |
| Complete Insert Compatibility1 | TRIB 32-1.000W 3Z-B |
