Associated Spring Raymond - 1/2" Bolt, Grade 1074 Steel, Oil Finish, Belleville Disc Spring - 0.071" High, 0.043" Thick
Item #: 91607077
Brand: Associated Spring Raymond
Model #: B1000043
Exact Tooling IR#: 04
Features and Benefits
Belleville disc springs, also known as conical washers, have a curved shape that creates a spring-like action. They are used in applications that require heavy loads.
| Product Specifications | |
|---|---|
| Type | Belleville Disc Spring |
| Bolt Size (Inch) | 1/2 |
| Bolt Size (mm) | 12.70 |
| System of Measurement | Inch |
| Material | Steel |
| Material Grade | 1074 |
| Thickness (mm) | 1.09 |
| Thickness (Decimal Inch) | 0.0430 |
| Overall Height (mm) | 1.80 |
| Overall Height (Decimal Inch) | 0.0710 |
| Deflection (Decimal Inch) | 0.0140 |
| Deflection (mm) | 0.36 |
| Minimum Inside Diameter (Decimal Inch) | 0.5050 |
| Minimum Inside Diameter (mm) | 12.83 |
| Maximum Outside Diameter (Decimal Inch) | 1.0000 |
| Maximum Outside Diameter (mm) | 25.40 |
| Load at Flat (Lb.) | 431.00 |
| Load at Flat (N) | 1917.18 |
| Minimum Load at Deflection (Lb.) | 213.00 |
| Minimum Load at Deflection (N) | 947.47 |
| Maximum Load at Deflection (Lb.) | 288.00 |
| Maximum Load at Deflection (N) | 1281.09 |
| Finish/Coating | Oil |
| Bolt Size (Decimal Inch) | 1/2 |
