Tritan - 1-15/16" ID, 8.1102" OAL x 4.4488" OAH Pillow Block - 5,216 Lb Static Cap, 7,868 Lb Dyn Cap, 6.26" Btw Mnt Hole Ctrs, 2-1/4" Base-to-Ctr Ht, Cast Iron/Steel
Item #: 92648211
Brand: Tritan
Model #: UCP210-31
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Pillow Block |
| Inside Diameter (Decimal Inch) | 1.9375 |
| Inside Diameter (Inch) | 1-15/16 |
| Width (Decimal Inch) | 2.3622 |
| Overall Length (Decimal Inch) | 8.1102 |
| Overall Height (Decimal Inch) | 4.4488 |
| Static Load Capacity (Pounds) | 5216.00 |
| Dynamic Load Capacity (Pounds) | 7868 |
| Distance Between Mounting Hole Centers (Decimal Inch) | 6.2600 |
| Material | Cast Iron/Steel |
| Distance Between Base And Center (Decimal Inch) | 2.2500 |
| Insert Material | 52100 Steel |
| Lock Type | Set Screw |
| Bolt Size (Inch) | 5/8 |
| Metric Bolt Size | 16.0000 |
