Mounted Bearings & Pillow Blocks; Bearing Insert Type: Wide Inner Ring; Bolt Hole (Center-to-center): 76.2 mm; Housing Material: Thermoplastic; Lock Type: Set Screw; Static Load Capacity: 2000.00; Number Of Bolts: 2; Maximum RPM: 4950.000; Series: UCPAPL;
Item #: 97171862
Brand: Tritan
Model #: UCPAPL206-20ASS
Product Specifications
| Bearing Insert Type | Wide Inner Ring |
| Bearing Bore Diameter | 1.25 in |
| Bolt Hole (Center-to-center) | 76.2 mm |
| Width (Inch) | 85 |
| Width (Decimal Inch) | 85 |
| Width (mm) | 85 |
| Bolt Size | 0.4375 |
| Base To Bore Centerline | 42.9 mm |
| Housing Material | Thermoplastic |
| Overall Length (Inch) | 102.00 |
| Overall Length (Decimal Inch) | 102.00 |
| Overall Length (mm) | 102.00 |
| Overall Length | 102.00 |
| Overall Width | 85 |
| Overall Height (Decimal Inch) | 38.1 mm |
| Overall Height (mm) | 38.1 mm |
| Overall Height (Inch) | 38.1 mm |
| Overall Height | 38.1 mm |
| Number Of Bolts | 2 |
| Static Load Capacity | 2000.00 |
| Dynamic Load Capacity | 3720.000 |
| Maximum Rpm | 4950.000 |
| Series | UCPAPL |
| Material | Thermoplastic |
| Insert Material | Stainless Steel |
| Lock Type | Set Screw |
