Indexable Plunge End Mills; Maximum Cutting Diameter: 1.0000 in; Shank Type: Modular; Maximum Depth Of Cut: 0.1500 in; Modular Connection Size: M12; Toolholder Style: FHU; Compatible Insert Style: WN.U; Compatible Insert Size Code: 04T3; Series: FHU; Numb
Item #: 97854541
Brand: Ingersoll Cutting Tools
Model #: 2914238
Product Specifications
| Maximum Cutting Diameter | 1.0000 in |
| Shank Type | Modular |
| Maximum Depth Of Cut | 0.1500 in |
| Modular Connection Size | M12 |
| Toolholder Style | FHU |
| Compatible Insert Style | WN.U |
| Compatible Insert Size Code | 04T3 |
| Series | FHU |
| Number of Flutes | 4 |
| Number Of Cutter Inserts | 4 |
| Flute Type | Straight |
| Overall Length/Projection (Decimal Inch) | 1.50 |
| Functional Length | 1.5000 in |
| Tool Application | Milling |
| Tool Performance | General Purpose |
| Primary Workpiece Material | Universal |
| Insert Holding Method | Screw |
| Minimum Cutting Diameter (Decimal Inch) | 0.7000 in |
| Through Coolant | Normal Pressure |
| Rake | Negative |
