TPMA 54 NV AC50E
Item #: FG312489281
Brand: Tool-Flo
Model #: 2489281
| Product Specifications | |
|---|---|
| Corner Radius (RE) | 0.009″ |
| Application | | Int Ext Threading On Edge | |
| Insert Thickness (S) | 0.252″ |
| Threads per Inch Maximum (TPIX) | 20 Threads/" |
| Inscribed Circle Diameter (IC) | 5/8″ |
| Threads per Inch Minimum (TPIN) | 4 Threads/" |
| Grade | AC50E AlTiN |
| Measurement Type | Inch |
| Cutting Direction (HAND) | Neutral |
| Body Material | Carbide |
| Angle | 5 Degrees |
| Thread Form Type (THFT) | 60?° Partial V-Thread Profile |
