BT30 x ER11M-70 - Collet Chuck

Item #: TE1216302
Manufacturer: Techniks
Mfg #: 16302

Technical Specifications:
*Brand Name: Techniks *Capacity: ER11M *Chuck Size: BT30 *Collets Included: No *Coolant Supply: Coolant-thru Spindle with Coolant Capable Retention Knob, sold separately *Head Length/Projection: 105mm *Model Number: 16302 *Mount: BT30 *Nut Diameter: 0.63 *Overall Length: 10.18 *Size/Range: .019 - .281 *Spindle Interface: BT30 *Weight: 1.05 lbs *Wrench Number: TE1204621

Description:
*Techniks Collet Chucks are balanced to 25,000 RPM at G2.5 tolerance *They are individually lab tested for accuracy and balance and come with their individual performance report *Techniks holders achieve 0.0001" or less T.I.R. as measured from the taper to the collet pocket *

Shipping Info:
*Actual Weight - 1.0500 *Dimensions - Height: 5.00 Length: 2.00 Width: 2.00
