Brand: Widia / Part #: 2748302
Item #: 97189062
Brand: Widia
Model #: 2748302
Product Specifications
| Thread Size (mm) | M3x0.5 |
| Chamfer | Plug |
| Thread Limit | D3 |
| Class Of Fit | 6H |
| Number Of Flutes | 2 |
| Material | High Speed Steel |
| Threads per Inch | 51 |
| Thread Direction | Right Hand |
| Flute Direction | Right Hand |
| Coating/Finish | Uncoated |
| Thread Depth (mm) | 7.87 |
| Coolant Through | No |
| Thread Length (mm) | 7.87 |
| Overall Length (mm) | 49.2800 |
| Thread Pitch (mm) | 0.50 |
| Thread Standard | Metric |
| Shank Diameter (mm) | 3.5800 |
| Material Application | Non-Ferrous Metal |
| Series | 2364/5364 |
