19003 5351TC M4X0.7 D4 2FL PLUG GUN
Item #: WK302747012
Brand: Widia
Model #: 2747012
| Product Specifications | |
|---|---|
| Thread Standard | Metric |
| Tool Type | Hand Tap |
| Thread Size | M4 × 0.7 |
| Connection Diameter Machine Side (DCONMS) | 0.168″ |
| Thread Diameter Size (TDZ) | M4 |
| Thread Cutting Part Length (THL) | 3/4″ |
| Thread Pitch (TP) | 0.7 mm |
| Flute Helix Angle (FHA) | 45 Degrees|CW |
| Thread Tolerance Class (TCTR) | D4 |
| Flute Type | Straight |
| Overall Length (OAL) | 2-1/8″ |
| Style | Plug |
| Chamfer | 3P-5P |
| Cutting Direction (HAND) | Neutral |
| Coating | TiCN |
| Coolant Supply Property (CSP) | External |
| Flute Count (NOF) | 2 |
| Measurement Type | Metric |
