M6X1.0 D5 3FL SP PT COMBO TAP-TICN
Item #: YG05T3315C
Brand: YG-1 Cutting Tools
Model #: T3315C
| Product Specifications | |
|---|---|
| Thread Standard | M |
| Special Feature | Black Ring |
| Thread Size | M7 × 1 |
| Connection Diameter Machine Side (DCONMS) | 0.318″ |
| Thread Diameter Size (TDZ) | M7 |
| Thread Cutting Part Length (THL) | 0.669″ |
| Thread Pitch (TP) | 1 mm |
| Flute Helix Angle (FHA) | 0 Degrees |
| Thread Tolerance Class (TCTR) | D5 |
| Drive Size (DRVS) | 0.238″ |
| Usable Length (LU) | 1.126″ |
| Tapping Prehole Diameter (Pre-hole) | 0.239″ |
| Overall Length (OAL) | 2.72″ |
| End Shape | Plug |
| Chamfer | 4P-5P |
| Shank Type | Square |
| Coating | TICN |
| Length Group | 3xD |
| Flute Count (NOF) | 3 |
| Measurement Type | Inch |
| Cutting Edge Material | HSS-EX |
| Series/List # | T3-C |
| Tool Type | Spiral Point Tap |
